ZED-5
페이지 정보
작성자최고관리자 댓글 0건 조회 1,050회 작성일 21-06-15 11:48본문
| Item | Specification |
|---|---|
| CPU | Intel® Celeron® Processor J1900 |
| Cache | 2M Cache, up to 2.42 GHz |
| Memory | DDR3L 1333MHz SO-DIMMx1, Up to 8GB |
| Storage | Built-in M.2 key-B support 2280 (SATA II) M.2 64GB or M.2 128GB or M.2 256GB |
| LAN Realtek | RTL 8111H 10/100/1000 Mb/s auto negotiation, RJ45 Connectorx1 |
| Display | 15inch TFT Liquid Crystal Display / 1024x768 / 4:3 |
| Processor Graphics | Intel® HD Graphics for Intel Atom® Processor Z3700 Series |
| Touch | 15ich Projected Capacitive waterproof Touch Panel |
| IC Reader | Option |
| USB | 4x USB 2.0 Port on Rear I/O 2x USB 2.0 Port Dual stack connectors |
| Sound Codec | Realtek Codec ALC662, supports Line-out |
| Back Panel I/O | 1x DC +12V Jack with Black Color(DIN-422) 1x DC Jack for DC 12V output (M2.1mm) 1x D-Sub 15 pin VGA output 4x RJ 45 (COM1~4 Port) 1x RJ45(COM6) 1x RJ45 (Gigabit LAN) |
| OS | Windows 10 IoT Enterprise Entry |
| Color | Black or White |
| Power | AC/DC ADAPTOR 12V 5000mA |
| Dual Display | 9.7" TFT (1024*768) LED Backlight |
